The Sram Level T Brakes
Made in Taiwan
Sram capitalizes on the same trail-taming brake technology that conquered the World Mountain Bike Championships, to deliver a powerful and consistent XC and trail-optimized brake set that keeps your capital in the bank. This budget-minded, MatchMaker™ compatible brake set provides all the power of its siblings, keeping you in complete control.
Specifications:
Series: Level T
Application: MTB, Trail, Cross Country
Pistons: 2 (21 mm)
Mount: post mount (IS with adapter)
Hydraulic Fluid: DOT 5.1
Rotor (Centerline) rotor not included
Brake Lever: included
Type: disc brake, hydraulic
Technical Information:
Brake Lever Material: aluminium
Brake Lever Housing: aluminium
Caliper Material: aluminium
Brake Pads: organic
Mount: left or right
Reach Adjust: yes (tools required)
Clamp: split / MatchMaker compatible
Front Hose Length: 850 mm
Rear Hose Length: 1580 mm
Technology: Bleeding Edge™, Direct Link™, DOT 5.1, Expandable Bladder, Heat Shield, PiggyBack™ Reservoir, TPC Plus™
Features:
- based on the Guide disc brake version (with the same pistons, seals and Reservoir), but smaller
- small brake lever with DirectLink™
- Level TL, TLM und Level Ultimate technologies used
- two bolt clamp
Technology:
DirectLink™:
SRAM's DirectLink lever design produces a solid, positive feel the second you squeeze the lever to engage the brake. It offers a no-nonsense solution to give you precise control.
DOT 5.1:
Heat is an enemy of any brake system, so advancements in heat management mean advancements in your ride. SRAM found that in the systems DOT 5.1 it takes almost three times longer to boil than DOT 4, thus allowing flawless, fade-free performance in even more extreme conditions.
Expandable Bladder:
SRAM's new brake lever design includes a reshaped bladder that helps regulate and reduce air bubbles. The bladder is specifically shaped to evacuate air from the lever and push the fluid exactly where it's needed. The result is improved back-pressure relief, which produces dependable braking power and consistency.
PiggyBack™ Reservoir:
The brake fluid reservoir on SRAM's latest lever design is optimized for both performance and ease of use. The PiggyBack Reservoir offers a simple, failsafe way to manage brake fluid, and also allows for ambidextrous lever placement-so you can switch your levers on the handlebar and run them moto without hassle.
TPC Plus™ (Timing Port Closure):
A hydraulic brake's timing port is the connection between the reservoir and the master cylinder bore. When the lever is squeezed, a cup seal passes this area and closes the port, which pressurizes the system. SRAM's new timing port closure system features durable seals and an ultra-smooth cylinder bore finish, producing dependable braking power and consistency.
Model Index:
front / gloss black:
- Type: front wheel
- Brake Hose Length: 900 mm
- Colour: gloss black
- Factory Number: 00.5018.105,000
Rear / Gloss Black:
- Type: rear wheel
- Brake Hose Length: 1750 mm
- Colour: gloss black
- Factory Number: 00.5018.105,001
Package Includes :
1 X New Set Front & Rear Sram Level T MTB Hydraulic Disc Brakeset (Plug & Play)
⚠️Note 🌟 no retail packaging
